Double side Film stripping Machine for stainless steel
Description
Film stripping machine for Thin film Solar
Stripping machine is waiting for you.
Constructed with a corrosion-resistant body and advanced PP material, double side stripping machine for stainless steel.
Stripping module assemble film separator and slag dryer. The film separator efficiently filters and separates ink residues and copper particles from the process solution.
The separated sludge settles into the bottom tray. The slag dryer working for drying the wet sludge into solid powder for easy collection and disposal.
This system keeps the solution clean and stable, extends its service life, and reduces maintenance frequency.
Equipped with Auto loader and auto unloader for convenient production.
Specifications
Stripping machine process includes Loading → Soak → Stripping → Recycle water1/2 → DI water washing → Squeezing → Cold blower → Hot air drying → Unloading
Dimension L7650xW1520xH2630MM
Effective working width 740mm
Stripping heating/cooling Electric heating
Stripping pump 7.5HP 1SET double side Stripping
Total power consumption 50.5KW
Guarantee 1year
Optional NAOH auto dosing system; Cooling chiller; waste gas scrubber(acid fume treatment);Slag dryer,Auto loader and Auto unloader
