Metal Etching machine for Stainless steel

Description

Metal Etchingmachine for Stainless steel

‍

Etching machineis waiting for you.

Effective etching spraying length is 8 meter, combined etching and stripping process in one machine.

Constructed with acorrosion-resistant body and advanced PP material. Adding one brushing moduleafter film stripping process for completely surface cleaning on stainless steel plate.

No items found.

Specifications

Etching machine process includes Loading → Etching → Recycle washing (1/2) → DI water rinsing → Squeezing → Inspection → Film Soak → Film stripping → Recyclewashing (3/4) → Brushing(2 Brush) → Recycle washing(5/6) →DI water washing → Squeezing → Cold blower →Hot air drying → Unloading

Dimension L24,450xW3,210xH2,670MM

Effective working width 1500mm

Etching heating/cooling Electric heating with cooling coil

Etching pump 7.5HP 8SET double side Etching

Total power consumption 220.4KW

Guarantee 1year

Optional Acid regeneration system; Cooling chiller; waste gasscrubber(acid fume treatment)
