PCB HASL Pre clean machine

Description

PCB HASL Preclean machine is waiting for you.

‍

The PCB HASL pre clean machine is used to clean the PCB surface before the HASL process. It removes oxidation, oils, and contaminants to ensure good solder coating quality.Equipped with excellent PP body, exhaust piping system, aluminum alloy air knife in drying module.

No items found.

Specifications

PCB HASL pre clean machine process includes Loading → Degreasing → Recycle water1/2 → City water 1 → Micro etch → Recycle water3/4 → City water 2→ Neutralization → Recycle water5/6/7 → City water 3 → Squeezing → Cold blower → Inspection → Coating solderingflux → Unloading

Dimension L10825xW2005xH2660MM

Effective working width 740mm

Developing heating/cooling Electric heating with cooling coil

Micro etch pump 5HP 2SET

Total power consumption 35.1W

Guarantee 1year

Optional waste gas scrubber(acid fume treatment)
