Stainless steel Etching machine for Electronics

Description

Stainless steel Etching machine for Electronics

‍

Etching machineis waiting for you.

Effective etching spraying length is 6 meter, equipped with a full set of pressure gauges to ensure precise etching for electronic parts.

Constructed with a corrosion-resistant body and advanced PP material. At the back side of the etching module, a chemical solution circulation tank is installed to maintain uniform concentration throughout the module, ensuring a consistent and high-quality etching effect.

No items found.

Specifications

Etching machine process includes Loading → Etching → Recycle washing (1/2) → DI water rinsing → Squeezing → Cold blower → Hot air drying→ Unloading

Dimension L14,600xW3700xH2,700MM

Effective working width 740mm

Etching heating/cooling Electric heating with cooling coil

Etching pump 10HP 8SET double side Etching

Total power consumption 112.3KW

Guarantee 1year

Optional Acid regeneration system; Cooling chiller;waste gas scrubber(acid fume treatment)
